Technical Specification |
|||||
| Brand | Seemex | ||||
IS CODE |
IS 15683 |
||||
Body |
Mild Steel |
||||
Type |
Constant Pressure | ||||
Extinguishing Media |
Clean Agent gas (NAF 4) | ||||
Propellent |
Nitrogen |
||||
Hydraulic Test Pressure |
35 kgf/cm2 |
||||
Service Pressure |
15 kgf/cm2 |
||||
Operating Temperature |
-10°C to +55°C |
||||
Min. Effective Discharge |
85% |
||||
Capacity |
1 kg |
2 kg |
4 kg |
6 kg |
9 kg |
Fire Rating |
8B |
1A Et. 8B |
2A Et 21B |
3A Et 21B |
4A Et 34B |
Discharge Time |
Min. 8 S |
Min. 8 S |
Min. 13 S |
Min. 13 S |
Min. 13 S |
Discharge Range |
1 Mtr. |
1 Mtr. |
2 Mtr. |
3 Mtr. |
3 Mtr. |
