Technical Specification |
Approval Body |
ISI Marked as per IS 15683 Mild Steel |
||||||
Brnad |
Seemex |
||||||
Type |
Constant Pressure / Cartridge Type |
||||||
Extinguishing Media |
As per IS: 14609 / IS: 4308 |
||||||
Propellent |
Nitrogen / CO2 |
||||||
Hydraulic Test Pressure |
35 kgf/cm2 |
||||||
Service Pressure |
15 kgf/cm2 |
||||||
Operating Temperature |
-30°C to +55°C |
||||||
Min. Effective Discharge |
85% |
||||||
Capacity |
1 kg |
2 kg |
4kg |
6 kg |
9kg |
4kg |
9kg |
Fire Rating |
1A Et 8B |
1A Et 8B |
2A Et 21B |
3A Et 21B |
4A Et 34B |
21B |
34B |
Discharge Time |
Min. 8 S |
Min. 8 S |
Min. 13 S |
Min. 13 S |
Min. 13 S |
Min. 13 5 |
Min. 13 5 |
Discharge Range |
1 Mtr. |
1 Mtr. |
2 Mtr. |
3 Mtr. |
3 Mtr. |
2 Mtr. |
3 Mtr. |
